NZ Hospital Washer Disinfector – Uniclean® PL II 10 | MMM Medical Washer
Compact, high performance washer disinfector for CSSD & clinical reprocessing
ARTG
 |
 |
 |
Features
The Uniclean® PL II 10 washer disinfector is a high‑performance, space‑efficient solution designed for CSSD departments, day surgery units and smaller hospitals that demand reliable, validated reprocessing without compromising floor space.
Engineered for clinical efficiency, this compact hospital washer delivers thorough cleaning and thermal disinfection across a wide range of reusable medical devices – making it an ideal choice for healthcare facilities seeking dependable hospital reprocessors in a smaller footprint.
With a width of just 700 mm, the Uniclean® PL II 10 maximises throughput while supporting lean CSSD layouts and modern workflow design.
Designed for Efficient Medical Device Reprocessing
The Uniclean® PL II 10 supports the validated reprocessing of:
- General surgical and MIS instruments
- Anaesthetic and respiratory equipment
- Ophthalmic instruments
- Containers, bowls, basins and receptacles
- OR footwear and reusable clinical accessories
This versatility makes it a trusted medical washer for facilities managing diverse instrument inventories within limited space.
Available in single‑door or double‑door configurations, the system supports unidirectional workflows and infection prevention best practice.
| Product Code | Product Description | Pack Size | Quote |
|---|---|---|---|
| Uniclean PL II 10-1 EL | MMM Group Uniclean PL II 10 Washer Disinfector, Single Door | ea | |
| Uniclean PL II 10-2 EL | MMM Group Uniclean PL II 10 Washer Disinfector, 2 Door | ea | |
| X | Transport Trolley | ea |
Key Benefits
- Compact CSSD washer design – ideal for tight plant rooms
- High cleaning and disinfection performance for busy environments
- Quiet operation suitable for clinical settings
- Front‑access service design reduces installation constraints
- Flexible rack system supports multiple instrument types
Product Highlights
- Ultra‑compact width: only 700 mm
- 12 DIN tray capacity for efficient throughput
- Smart HMI with large 7″ colour touchscreen
- 4D Aqua Frame rack technology for consistent cleaning coverage
- Designed for high serviceability and uptime
Standard Features
The Uniclean® PL II 10 washer disinfector includes a comprehensive set of features to support safe, repeatable and validated processes:
- Hygienic chamber and external surfaces, designed for easy cleaning
- 12 DIN tray capacity (effective chamber volume: 216 litres)
- Industrial PLC housed in an IP55‑rated control cabinet
- Intuitive Smart HMI with clear visual process status
- Front‑side service access (no side clearance required for pass‑through units)
- Rack loading and water docking access from all sides
- Integrated 4D Aqua Frame rack design
- Smooth‑glide internal transport rollers
- Intelligent water and energy management system
- Process Parameter Verification (PPV):
- Air temperature
- Water temperature
- Pump pressure monitoring
- HEPA H13 filtered airflow
- AISI 316L stainless steel wash chamber
- Electrically operated vertical glass doors with clear process visibility
- Electric tank and air heating
- 3‑colour LED chamber lighting
- Automated thermal disinfection with A₀ or temperature / holding‑time control
These features ensure dependable performance across demanding hospital washer applications.
Technical Data
| Dimensions (mm) | Uniclean PL II 10-1 EL | Uniclean PL II 10-2 EL |
| Product Outer (H x W x D) | 2,300 x 700 x 830 | 2,300 x 700 x 777 |
| Product Chamber (H x W x D) | 688 x 523 x 600 | 688 x 523 x 600 |
| Chamber Volume Net / Gross (L) | 216 | 216 |
| Load Capacities | ||
| Surgical Instruments DIN Sieve Trays | 12 | 12 |
Optional Configuration & Connectivity
The Uniclean® PL II 10 can be configured to meet specific CSSD and facility requirements, including:
- Increased loading height (up to 2,000 mm)
- Integrated or DIN A4 cycle report printers
- Secondary display on the unloading side
- Barcode‑based rack and program recognition
- Automatic rack return function
- Intelligent Service Advisor (ISA)
- Interface to digital documentation platforms (e.g. RUMED360®)
- Remote diagnostics and service access
- Conductivity monitoring and dosing verification
- Additional dosing pumps (up to 3)
- Deionised water pre‑heating options
- Exhaust air condenser and drainage pump
Hot water connection and under‑floor media connections
Accessories & Workflow Support
- Wide range of dedicated loading racks
- Transport trolleys optimised for ergonomic handling
- Digital documentation and traceability solutions
Relevant Product
- Uniclean PL II 15 Washer Disinfectors
- Uniclean PL II 30 Washer Disinfectors
- MMM Group Concept 15.30
- Washer Disinfector Technology
- CSSD Automation & Digitalisation
- Selectomat PL Compact Steam Sterilisers
- Selectomat PL Steam Sterilisers
- Selectomat SL Steam Sterilisers
- Low Temp Plasma Steriliser
- RUMED360
Applications
- CSSD
- Healthcare Facilities
- Large Dental Practices
